SI® Solid Body Press-In Insert
Superior Threaded Connections in Plastics Applications
Creating reliable threaded connections in plastic components demands a fastener that delivers on both pullout strength and torque resistance without complex installation requirements. The new SI® Solid Body Press-In Insert with Retention Fin Design provides exceptional performance where it’s needed most.
This non-slotted, cold press insert features an innovative approach that outperforms standard press-in inserts – creating strong, reusable threads without requiring heat or ultrasonics for installation.
Exceptional Performance from Unique Retention Fin Design
The SI® Solid Body Press-In Insert delivers exceptional performance metrics that provide secure connections in your most demanding applications:
- Retention Fin/Barbed Feature provides significantly better pullout performance than other solid body press-in inserts on the market
- Pullout values in ABS plastic reaching up to 142 lbs. for larger sizes
- Torque-out values exceeding 36 in. lbs.
Versatility Across Industries and Applications
The SI® Solid Body Press-In Insert excels in harder plastics, including most thermoset resins, making it ideal for diverse applications across multiple industries.
Automotive
- Interior panels
- Dashboards
- Seating Components
- Consoles
Electronics
- Circuit Board Protection
- Electronic Enclosures
Medical
- Device Housings
- Control Knobs and Switches
Consumer Goods
- Sporting Equipment
- Musical Instruments
- Household Products
Furniture
- Modular Cabinetry
- Shelving Systems
Simple 3-Step Installation
Installing the SI® Solid Body Press-In Insert is straightforward and efficient. No specialized equipment or complex methods are required – just a standard arbor press – saving time and reducing costs while providing consistent, reliable results.
Step 1.
Prepare properly sized mounting hole (molded holes preferred for dimensional accuracy)
Step 2.
Align and orient the fastener in the mounting hole
Step 3.
Apply appropriate pressure until the fastener is fully seated
View a video example below:
SI® Solid Body Press-In Insert At-a-Glance
- Retention Fin/Barbed Feature significantly improves pullout resistance compared to standard press-in inserts
- Right-Handed Knurls cut directly into host material for superior torque resistance
- Cold Press Installation eliminates need for ultrasonic or heat insertion equipment
- Material Versatility with brass, stainless steel, and aluminum options
- Comprehensive Size Range in both inch and metric thread sizes
- Multiple Configuration Options including standard straight wall installation designs (IPA/IPB/IPC) and flanged-head designs for higher tensile pull loads in reverse entry applications (IPFA/IPFB/IPFC)
Tested for Proven Performance
Fastener performance is critical to your product’s success. Each SI® Solid Body Press-In Insert goes through rigorous testing so it meets or exceeds market standards, with protocols measuring:
- Installation force requirements
- Pullout strength in various materials
- Torque-out resistance
- Performance in diverse environmental conditions
The results speak for themselves – SI® inserts deliver exceptional mechanical integrity and reliability across all critical test parameters.
FREE Custom Testing Services
Our free custom testing services ensure that SI® Solid Body Press-In Inserts will meet your specific application requirements. Work directly with our team to:
- Evaluate your application needs
- Test in your specific material
- Document and verify performance metrics
- Get comprehensive test reports and recommendations
Move forward with confidence knowing your SI® parts are verified to perform in your application.
The SI® Difference
When you choose SI® inserts, you’re partnering with a trusted leader in fastening innovation.
Our comprehensive product portfolio, manufacturing expertise, testing protocols, and expert customer support at the local level ensure you receive the best possible solutions for your most challenging applications.
Have a question? Talk to an Engineer
Connect with an SI® engineering expert today and see what’s possible.
