CLS-632-2
Self-Clinching Nuts – Types S, SS, CLS, CLSS, SP
CLS-632-2
Self-Clinching Nuts – Types S, SS, CLS, CLSS, SP
Self-clinching nuts are installed by placing them in properly sized holes in sheets and applying a parallel squeezing force to the head of the nut. The sheet metal surrounding the head cold flows into an undercut thereby making the fastener an integral part of the sheet. A serrated clinching ring prevents the fastener from rotating after installation.
Provide load-bearing threads in thin sheets with high pushout and torque-out resistance.
Type CLA is recommended for use in steel or aluminum sheets HRB (Rockwell "B" scale) 50 or less and HB (Hardness Brinell) 82 or less.
Types CLS / CLSS are recommended for use in steel or aluminum sheets HRB (Rockwell "B" scale) 70 or less and HB (Hardness Brinell) 125 or less.
Types S / SS are recommended for use in steel or aluminum sheets HRB (Rockwell "B" scale) 80 or less and HB (Hardness Brinell) 150 or less.
Type SP is recommended for use in stainless steel sheets HRB (Rockwell "B" scale) 90 or less and HB (Hardness Brinell) 185 or less.
Especificaciones
- Código de rosca
- 632
- Tamaño de rosca
- .138-32 (#6-32)
- Especificación de rosca
- 2B, ASME B1.1
- Código del vástago
- 2
- Material del inserto
- 300 Series Stainless Steel
- Acabado Estandard
- Passivated and/or tested per ASTM A380
- Para uso en láminas de dureza
- HRB 70 / HB 125 or Less
- Categoría del producto
- Self-Clinching Nuts – Types S, SS, CLS, CLSS, SP – Unified
- Tipo de rosca
- Internal
- Marca
- PEM
- Producto de la familia PEM
- CLS
- Tipo de producto
- Tuercas
- A Vástago máx
- 0.054in
- E ± .010_in
- 0.28in
- Hole Size in Sheet +.003 – .000_in
- 0.1875in
- Min. Dist. Hole C/L to Edge_in
- 0.22in
- C Max._in
- 0.187in
- T ± .010_in
- 0.07in
